Factory model 65-16K-65

Russian-Pattern Fire Department Connection

A two-inlet fire department connection with a DN100 bottom flange and two DN65 / KY66 fire-service inlets.

65-16K-65 DN100 bottom flange 2 × DN65 / KY66 1.6 MPa / 16 bar

The model, connections and pressure values are user-confirmed selection data. Material, internal check-valve construction, exact coupling compatibility, flange dimensions, installation requirements and certification are not asserted.

Product image

Representative front view

The user-supplied image identifies the product family and visible twin-inlet arrangement. Confirm the exact ordered flange, mating coupling and internal construction separately.

User-supplied front image of a red Russian-pattern fire department connection with two capped inlets and retaining chains

65-16K-65 front view1 / 1

Specifications

Confirmed selection data

Working pressure and strength test pressure are kept as separate fields. Unconfirmed construction and installation details remain quotation-specific.

Product family: Russian-pattern fire department connection with two fire-service inlets
Factory Model: 65-16K-65
System connection: DN100 bottom flange
Fire-service inlets: 2 × DN65 / KY66
Working pressure: 1.6 MPa / 16 bar
Strength test pressure: 2.4 MPa / 24 bar
Confirmed accessories: Two caps with retaining chains
Material and finish: To be confirmed with the quotation
Internal construction: To be confirmed with the quotation
Coupling compatibility: To be confirmed with the quotation
Flange dimensions: To be confirmed with the quotation
Installation requirements: To be confirmed with the quotation
Packing: To be confirmed with the quotation
Image evidence scope: User-supplied representative front image; not exact flange, mating or internal-structure proof

Available selection

Confirmed factory-model row

The table preserves the single confirmed factory-model configuration without creating unverified variants.

Factory Model	System connection	Fire-service inlets	Working pressure	Strength test pressure	Confirmed accessories
65-16K-65	DN100 bottom flange	2 × DN65 / KY66	1.6 MPa / 16 bar	2.4 MPa / 24 bar	Two caps with retaining chains

KY66 is retained as confirmed interface text; it does not establish certification or compatibility with every mating component.

Quotation confirmation

Confirm the flange and mating coupling

Send the flange dimensions, mating-coupling requirement and installation details so the supplied configuration can be locked in the quotation.

Flange and mating couplingProvide the required flange drilling and the destination-market mating coupling details.

Material and internal constructionConfirm body material, finish and any required internal check-valve arrangement.

Installation requirementProvide mounting orientation, available space and system-side installation requirements.

Order informationProvide quantity, destination, packing and required documents.

Send your 65-16K-65 requirement

Include flange dimensions, mating coupling, installation requirement, quantity and destination.
