Red-and-Black Long-Riser Outdoor Fire Hydrant
Source connection or dimension data: inlet 4 in (100 mm); outlet 2.5 in NH · inlet 6 in (150 mm); outlet 2.5 in NH
4 directly selectable configurations from the supplied catalog
Pillar and Standpipe Fire Hydrant Configurations
Use the configuration images to identify the required product, then confirm connection, material and performance data with the quotation.
4 illustrated configurations
Supplied electronic catalog page 31
To be confirmed with the quotation
The final specification and product arrangement are confirmed in the quotation and approved drawing.
Available configurations
Red-and-Black Twin-Valve Long-Riser Fire Hydrant
Source connection or dimension data: inlet 4 in (100 mm); outlet 2.5 in BS336 · inlet 6 in (150 mm); outlet 2.5 in BS336
Red Chained-Cap Standpipe Fire Hydrant
Source connection or dimension data: inlet 4 in (100 mm); outlet 2.5 in NH · inlet 6 in (150 mm); outlet 2.5 in NH
Red Twin-Handwheel Standpipe Fire Hydrant
Source connection or dimension data: inlet Ø100 mm; outlet 2.5 in BS336 · inlet 6 in (150 mm); outlet 2.5 in BS336
The final specification and product arrangement are confirmed in the quotation and approved drawing.
Configuration images
4 configurations to compare
Open each image to compare the general arrangement. Confirm small details, threads and cast markings against an original photo, mating sample or approved drawing.
Red-and-Black Long-Riser Outdoor Fire Hydrant1 / 4
Data scope
Confirmed source scope and quotation checks
Visible connection and dimension values were transcribed from the catalog to support configuration selection. Final order specifications are confirmed in the quotation.
- Product family
- Pillar and Standpipe Fire Hydrant Configurations
- Available configurations
- 4 illustrated configurations
- Selection data source
- Supplied electronic catalog page 31
- CHUANWEI factory model
- To be confirmed with the quotation
- Technical data status
- Preliminary catalog data; order confirmation required
Available configurations
Configurations and linked source-catalog data
Each row shows a configuration and the connection or dimension entries visible in the supplied catalog.
| Configuration | Source connection or dimension data |
|---|---|
| Red-and-Black Long-Riser Outdoor Fire Hydrant | inlet 4 in (100 mm); outlet 2.5 in NH · inlet 6 in (150 mm); outlet 2.5 in NH |
| Red-and-Black Twin-Valve Long-Riser Fire Hydrant | inlet 4 in (100 mm); outlet 2.5 in BS336 · inlet 6 in (150 mm); outlet 2.5 in BS336 |
| Red Chained-Cap Standpipe Fire Hydrant | inlet 4 in (100 mm); outlet 2.5 in NH · inlet 6 in (150 mm); outlet 2.5 in NH |
| Red Twin-Handwheel Standpipe Fire Hydrant | inlet Ø100 mm; outlet 2.5 in BS336 · inlet 6 in (150 mm); outlet 2.5 in BS336 |
Quotation confirmation
Confirm the configuration before production
Send the configuration image, size, connection, material, working pressure, quantity and destination. The quotation and approved drawing lock the final supply specification.
Connection and sizeConfirm inlet/outlet direction, nominal size, thread, coupling or flange against a mating sample or drawing where required.
Material and finishConfirm body material, alloy grade, seal material, finish and color. The visible color does not establish the material.
Pressure and documentsState working pressure, test pressure, medium and required documents with the quotation request.
Image and approved drawingReview the original photo or sample and approved drawing to confirm small details, markings and dimensions before production.
Send your Pillar and Standpipe Fire Hydrant Configurations requirement
Include the configuration, connection, material, pressure, quantity and destination country.
