Brass-Finish Double-Lug Fire Hose Coupling
Source connection or dimension data: inlet 1.5 in NH; outlet 38 mm · inlet 2 in NH; outlet 51 mm · inlet 2.5 in NH; outlet 63 mm
5 directly selectable configurations from the supplied catalog
Fire Hose Couplings — NH, GOST, UNI and BS 336
Use the configuration images to identify the required product, then confirm connection, material and performance data with the quotation.
5 illustrated configurations
Supplied electronic catalog page 20
To be confirmed with the quotation
The final specification and product arrangement are confirmed in the quotation and approved drawing.
Available configurations
Brass-Finish Claw Fire Hose Coupling
Source connection or dimension data: inlet 2 in GOST; outlet 51 mm · inlet 2.5 in GOST; outlet 63 mm
Brass-Finish Ring-Type Fire Hose Coupling
Source connection or dimension data: inlet UNI45; outlet 45 mm · inlet UNI70; outlet 70 mm
Brass-Finish Double-Latch Fire Hose Coupling
Source connection or dimension data: inlet 1.5 in BS336; outlet 38 mm · inlet 2 in BS336; outlet 51 mm · inlet 2.5 in BS336; outlet 38 mm · inlet 2.5 in BS336; outlet 51 mm · inlet 2.5 in BS336; outlet 63 mm
Silver-Finish Red-Seal Fire Hose Coupling
Source connection or dimension data: inlet 1.5 in; outlet 38 mm · inlet 2.5 in; outlet 63 mm
The final specification and product arrangement are confirmed in the quotation and approved drawing.
Configuration images
5 configurations to compare
Open each image to compare the general arrangement. Confirm small details, threads and cast markings against an original photo, mating sample or approved drawing.
Brass-Finish Double-Lug Fire Hose Coupling1 / 5
Data scope
Confirmed source scope and quotation checks
Visible connection and dimension values were transcribed from the catalog to support configuration selection. Final order specifications are confirmed in the quotation.
- Product family
- Fire Hose Couplings — NH, GOST, UNI and BS 336
- Available configurations
- 5 illustrated configurations
- Selection data source
- Supplied electronic catalog page 20
- CHUANWEI factory model
- To be confirmed with the quotation
- Technical data status
- Preliminary catalog data; order confirmation required
Available configurations
Configurations and linked source-catalog data
Each row shows a configuration and the connection or dimension entries visible in the supplied catalog.
| Configuration | Source connection or dimension data |
|---|---|
| Brass-Finish Double-Lug Fire Hose Coupling | inlet 1.5 in NH; outlet 38 mm · inlet 2 in NH; outlet 51 mm · inlet 2.5 in NH; outlet 63 mm |
| Brass-Finish Claw Fire Hose Coupling | inlet 2 in GOST; outlet 51 mm · inlet 2.5 in GOST; outlet 63 mm |
| Brass-Finish Ring-Type Fire Hose Coupling | inlet UNI45; outlet 45 mm · inlet UNI70; outlet 70 mm |
| Brass-Finish Double-Latch Fire Hose Coupling | inlet 1.5 in BS336; outlet 38 mm · inlet 2 in BS336; outlet 51 mm · inlet 2.5 in BS336; outlet 38 mm · inlet 2.5 in BS336; outlet 51 mm · inlet 2.5 in BS336; outlet 63 mm |
| Silver-Finish Red-Seal Fire Hose Coupling | inlet 1.5 in; outlet 38 mm · inlet 2.5 in; outlet 63 mm |
Quotation confirmation
Confirm the configuration before production
Send the configuration image, size, connection, material, working pressure, quantity and destination. The quotation and approved drawing lock the final supply specification.
Connection and sizeConfirm inlet/outlet direction, nominal size, thread, coupling or flange against a mating sample or drawing where required.
Material and finishConfirm body material, alloy grade, seal material, finish and color. The visible color does not establish the material.
Pressure and documentsState working pressure, test pressure, medium and required documents with the quotation request.
Image and approved drawingReview the original photo or sample and approved drawing to confirm small details, markings and dimensions before production.
Send your Fire Hose Couplings — NH, GOST, UNI and BS 336 requirement
Include the configuration, connection, material, pressure, quantity and destination country.
