Pillar and Standpipe Fire Hydrant Configurations

Use the configuration images to identify the required product, then confirm connection, material and performance data with the quotation.

3 illustrated configurations

Configuration images are illustrations. Request the product photo, connection and performance details for your selected configuration before ordering.

Available configurations

Outdoor Fire Hydrant — NH Outlet — USS-020 / USS-021

Catalog configuration illustration of Outdoor Fire Hydrant — NH Outlet — USS-020 / USS-021

Connection or dimension references: inlet 4 in (100 mm); outlet 2.5 in NH · inlet 6 in (150 mm); outlet 2.5 in NH

Twin-Valve Fire Hydrant — BS336 Outlet — BS-031 / BS-032

Catalog configuration illustration of Twin-Valve Fire Hydrant — BS336 Outlet — BS-031 / BS-032

Connection or dimension references: inlet 4 in (100 mm); outlet 2.5 in BS336 · inlet 6 in (150 mm); outlet 2.5 in BS336

Standpipe Fire Hydrant — NH Outlet — USS-022 / USS-023

Catalog configuration illustration of Standpipe Fire Hydrant — NH Outlet — USS-022 / USS-023

Connection or dimension references: inlet 4 in (100 mm); outlet 2.5 in NH · inlet 6 in (150 mm); outlet 2.5 in NH

Specifications

Product selection details

Compare connection and dimension references to choose your configuration. Final order specifications are confirmed with the quotation.

Product family
Pillar and Standpipe Fire Hydrant Configurations
Available configurations
3 illustrated configurations

Available configurations

Configurations and connection references

Compare the configuration and connection or dimension references in each row.

ConfigurationConnection or dimension references
Outdoor Fire Hydrant — NH Outlet — USS-020 / USS-021inlet 4 in (100 mm); outlet 2.5 in NH · inlet 6 in (150 mm); outlet 2.5 in NH
Twin-Valve Fire Hydrant — BS336 Outlet — BS-031 / BS-032inlet 4 in (100 mm); outlet 2.5 in BS336 · inlet 6 in (150 mm); outlet 2.5 in BS336
Standpipe Fire Hydrant — NH Outlet — USS-022 / USS-023inlet 4 in (100 mm); outlet 2.5 in NH · inlet 6 in (150 mm); outlet 2.5 in NH

Connection and dimension references are selection aids. Confirm the final model, flow direction, thread or flange, material, pressure and drawing before production.

Quotation confirmation

Confirm the configuration before production

Start with the configuration and quantity. Add size, connection, working pressure and destination when available; we will review the supply details with you.

Connection and sizeConfirm inlet/outlet direction, nominal size, thread, coupling or flange against a mating sample or drawing where required.
Material and finishConfirm body material, alloy grade, seal material, finish and color. The visible color does not establish the material.
Pressure and documentsState working pressure, test pressure, medium and required documents with the quotation request.
Image and approved drawingReview the original photo or sample and approved drawing to confirm small details, markings and dimensions before production.

Send your Pillar and Standpipe Fire Hydrant Configurations requirement

Start with the configuration and quantity. Size, connection and project requirements can follow.
